Hydraulic Telescopic Cylinders (2-8 Stage) for Tipper Trucks
Wide Configuration Range (2 to 8 Stages): From compact 2-stage hoists for light trailers to massive 8-stage cylinders for heavy-duty multi-axle tippers and mining rigs.
Fully Custom Design & Tailored Stroke: Engineered precisely to your vehicle’s specifications. We produce custom stroke lengths, mounting types, port locations, and operating pressure ratings according to your technical drawings or requirements.
Precision Cold-Drawn Seamless Tubes: Built using premium St52 / E355 grade cold-drawn seamless steel tubing. Cold-drawing ensures superior surface finish, tight dimensional tolerances, and high tensile strength to prevent bending under maximum payload angles.
Made in Turkey: Precision-engineered with Turkish craftsmanship, offering high European quality standards at direct-factory export pricing.
Single & Double-Acting Options:
Single-Acting: High-efficiency hydraulic extension with reliable gravity-assisted retraction.
Double-Acting: Powered extension and powered retraction for sticky materials, steep tipping angles, or specialized industrial dumpers.
Hard Chrome Plating & Premium Seals: Every stage is hard chrome-plated and fitted with high-pressure polyurethane and PTFE seals to prevent fluid leaks, resist harsh environmental conditions, and reduce maintenance downtime.
Technical Specifications
| Specification | Details |
| Number of Stages | 2, 3, 4, 5, 6, 7, and 8-Stage Options |
| Customization | Fully Customizable (Custom stroke, mounting, and port sizes) |
| Tubing Material | High-Grade Cold Drawn Seamless Steel (St52 / E355) |
| Operation Type | Single-Acting / Double-Acting |
| Surface Finish | Hard Chrome Plated & Micro-Polished |
| Working Pressure | Standard 190 – 220 Bar (Custom pressure ratings on request) |
| Application | Tipper Trucks, Dump Trailers, Side Tippers, Mining Vehicles |
| Country of Origin | Made in Turkey (Turkiye) |
Applications
Our multi-stage hydraulic telescopic cylinders are ideal for a wide array of commercial transport, construction, and agricultural applications:
Rear-dump tipper trucks and tipping semi-trailers (light to heavy-duty payloads)
Multi-directional side-tipping and agricultural trailers
Mining and aggregate off-road dump trucks
Municipal refuse trucks, container lifters, and waste management equipment
Why Choose Bomanti Hydraulic Systems?
At Bomanti, we combine flexible custom manufacturing with strict quality control to support vehicle bodybuilders, fleet operators, and hydraulic distributors globally. Sourcing direct from Turkey ensures reliable supply chain logistics, high structural reliability, and low total cost of ownership.
Request a Quote or Custom Technical CAD Drawing
Have specific stroke requirements or custom mounting dimensions?
📩 Contact our engineering and export team today at bomanti.net to discuss your custom project or request a quote.
